The novel coronavirus disease 2019 (COVID-19) is caused by a positive-sense single-stranded ribonucleic acid (RNA) virus . It was first detected in Wuhan, China, in December 2019 as declared by WHO, and it was declared a global pandemic in March 2020 . The first case in India was detected in January 2020 in Kerala . Though initially thought to affect only the respiratory system, many types of research, including this, demonstrate extrapulmonary involvement. Several studies reveal that the atypical presentation of the disease might be due to systemic involvement and hypercoagulable state with micro and macro-angiopathy . One of the manifestations of the hypercoagulable state is acute limb ischemia. Its presentation can be in the form of chilblains, bullae, acral cyanosis, bruising, blood blisters, dry gangrene, or life-threatening acute limb ischemia . A few patients who present early recover with medical management. However, unfortunately, most patients need an amputation due to delayed presentation or rapidly progressing disease. Some patients also succumbed due to sepsis. Here we present a case series of acute lower limb ischemia following COVID-19 infection and their treatment strategy. Informed consent was taken from both the patients included in the study.
Case Report 1
A 45-year-old gentleman presented to the emergency department with blackish discolouration of the left lower limb for four days. It initially started at a digital level and gradually progressed up to the level of mid-thigh. This was associated with severe pain due to which he was unable to walk. He was diagnosed to have hypertension for the last eight years and was on oral antihypertensive medications regularly. He had no history of any cardiac diseases, diabetes, or transient ischemic attack. He did not have any history of smoking or any family history of atherosclerotic disease.
He tested COVID-19 RT-PCR positive 16 days back, for which he was admitted to a tertiary care hospital since he had difficulty in breathing. Initially, he was managed in the ward for one day and then shifted to ICU given clinical deterioration. His inflammatory markers like c-Reactive Protein (CRP), ferritin, D-dimer, and IL-6 were raised. During the ICU stay, he received steroids, antibiotics, anti-virals, and antithrombotics. He was shifted out of ICU to the ward after 10 days of ICU stay and then discharged from the hospital after two more days of observation. There was no specific history to explain the unfortunate event except for the recent history of COVID-19.
At presentation, the patient was dehydrated and had tachycardia, but blood pressure was normal. The respiratory system examination revealed bilateral vesicular breath sound heard all over the chest without any added abnormal sound. The cardiovascular system examination was found to be normal. On local examination, wet gangrene of the left lower limb was present with the line of demarcation at the proximal thigh region (Figure 1).
There were few bullae present over the medial aspect of the thigh. There was tenderness and a local rise of temperature over the thigh region. The distal limb was cold to touch. All the pulses distal to femoral pulse were absent (popliteal, anterior and posterior tibial, and dorsalis pedis). There was a loss of motor and sensory activity below the knee. The patient was started on empirical broad-spectrum antibiotics and heparin injection. Subsequently, CT angiography was done, which revealed complete occlusion of the blood supply to the left lower limb from the level of the common iliac artery (Figure 2, 3).
Echocardiography revealed no abnormality. Blood investigations showed neutrophilic leucocytosis with a deranged prothrombin time/ international normalized ratio (PT/INR). The lipid profile of the patient was found to be normal. Since gangrene was already established, the option of thrombolysis was ruled out. As the limb was non-salvageable, a left above knee amputation was planned (Figure 4).
Intraoperatively, the femoral artery and vein were found to be filled with thrombus at the level of amputation. Below the level of amputation, the muscles of the anterior and medial compartments were necrosed with no response to any stimulation and were having a putrid smell. The sciatic nerve and saphenous nerve were sloughed off and were felt like butter when touched. All posterior compartment muscles were seemed viable and had mild to moderate responses to stimulation. The stump was left open given poor vascularity, and the daily dressing was done. The wound was closed secondarily on a post-operative day five, following which the patient recovered without any complications and was discharged on post-operative day 13.
Case Report 2
Another patient, a 55-year-old gentleman, presented to the emergency department chief complaints of blackish discolouration of the left lower limb up to the knee for five days. It was started distally involving the toes at first, which gradually progressed to affect the limb up to the knee. He had no history of diabetes, cardiac disease, hypertension, or history of transient ischemic attack. There was no family history of any atherosclerotic disease. He was not a smoker. Notably, he was diagnosed as COVID-19 positive 21 days back. The inflammatory markers like CRP, ferritin, D-dimer, and IL-6 were raised. For this, he received treatment at a tertiary care hospital for 15 days with antibiotics, steroids and Anti-virals without anticoagulants (as he was categorised to have mild to moderate grade disease).
On examination, he had tachycardia and tachypnoea. The respiratory system examination revealed bilateral vesicular breath sound heard all over the chest without any added abnormal sound. The cardiovascular system examination showed no abnormality. Local examination of the left lower limb revealed gangrene below the knee joint (Figure 5).
There was redness, edema, skin exfoliation, and tenderness up to the thigh. The foot distal to the ankle joint was cold. All the pulses were absent except the feeble left femoral pulse. The pulses in the opposite limb and other peripheral pulses were well felt. There was no motor activity below the knee. The patient was started on empirical broad-spectrum antibiotics. During the investigation, CT angiography showed complete occlusion of the mid superficial femoral artery, popliteal artery, and infra popliteal artery with poor collateral status (Figure 6, 7).
The echocardiography of the patient was found to be normal. Blood investigations revealed neutrophilic leucocytosis. As there was already an onset of gangrene over the distal part of the limb, revascularisation was out of option. So the patient was left with no options other than left above knee amputation. Intraoperative findings revealed that the femoral artery and vein were filled with thrombus at the level of amputation. Below the level of amputation, the muscles of the anterior compartments were found to be gangrenous with no response to any stimulation with a putrid smell. The sciatic nerve and saphenous nerve were sloughed off and seemed like butter when touched. All posterior and medial compartment muscles appeared viable and had mild to moderate responses to stimulation. As the vascularity was adequate, the stump was closed primarily (Figure 8). The post-operative hospital stay was uneventful, and the patient was discharged on post-operative day 10.
The symptoms of COVID-19 are graded from mild to moderate to severe and very severe. While fever, cough, headache, anosmia, ageusia, body ache, diarrhoea constitute mild to moderate grade, systemic involvements (pneumonia, myocarditis, stroke, and other coagulation abnormalities) place patients in the severe grade of the disease. A large proportion of the patients are recovering completely after the viral infection, except a few having minor complaints of cough and shortness of breath. Patients presenting with severe to very severe diseases usually have significant lung damage and fibrosis . These are the patients who are at higher risk of developing extra pulmonary post COVID complications. One school of thought is that the virus affects the heart, kidney, small intestine, testes, and vascular endothelium through angiotensin-converting enzyme 2 (ACE2) receptors . Another group of investigators hypothesised that the prothrombotic state is caused directly by the virus damaging the endothelial cells through ACE-2 receptors of alveoli leading to endothelial cell activation and dysfunction . Among the various manifestations of the COVID-19 infection, the prothrombotic effects of this virus are now taking a toll worldwide. Various studies have documented venous thromboembolic events and multiple arterial thrombotic manifestations ranging from lower extremity arterial occlusion to stroke . The virus persuades an inflammatory cascade, leading to a prothrombotic state, causing microvascular and macrovascular endothelial damage . In addition to this, inhibition of fibrinolysis exaggerates the thrombotic event. Liver secrets fibrinogen and thrombopoietin by the stimulation of interleukin 6 and damages the endothelium by activating the extrinsic pathway of the coagulation cascade . A Dutch study revealed that patients with severe COVID-19 infection and admitted to ICU have a 31% increased risk of thrombotic complications . Several studies showed that even after treating the severe COVID-19 patients with prophylactic or therapeutic antithrombotic therapy, the percentage of thrombotic complications is still high . One of our patients was admitted to ICU and had a long ICU stay with prolonged antithrombotic therapy. Still, he developed limb ischemia on the 13th day after detection of COVID-19, though he was on antithrombotic agents. Other patient had mild to moderate disease and was not given any antithrombotic. He complained of blackish discolouration of the lower limb on the 11th day post-COVID-19 detection. So it remains a dilemma that how to prevent these catastrophic thrombotic events?
Another enthralling finding in both of our cases was a butter-like feeling of the sciatic nerve sheath. An Italian study by Zanin et al. revealed that the novel coronavirus could cause extensive nervous system demyelination . This may be the explanation of our intraoperative findings. As more and more data regarding the post-COVID-19 thrombotic complications are getting surfaced worldwide, the challenges to treat this catastrophic event are also becoming tougher. A single-institution study done by Klok et al. showed the cumulative incidence of arterial or venous complications was around 57% . Perini et al. reported four patients with post-COVID-19 acute limb ischemia . Another Italian study revealed 20 patients with acute limb ischemia as an extrapulmonary post-COVID-19 thrombotic complication . We are reporting these two post-COVID-19 acute lower limb ischemia as index cases in one of the largest tertiary care hospitals in Eastern India.
Both patients in our series of two cases of acute lower limb ischemia were discharged following complete treatment of primary COVID-19 infection. It was the period of home isolation after discharge that led to the complication. The delay in seeking medical help cost both the patients their limbs. The patient’s leg probably could have been saved if he had presented early. There is no established guideline for patients recovering from COVID-19 infection. Therefore, keeping the potentially debilitating effects of gangrene in mind, all patients should be seen as soon as possible if they recognise any signs or symptoms of limb ischemia (tingling, numbness, or discolouration). As one of the COVID-19 extrapulmonary manifestations, limb ischemia may present in the emergency department. Therefore, the history of COVID-19 should be taken into account when evaluating these patients. There has been no specific guideline developed to prevent or manage thrombosis complications. It remains a dilemma whether to use or not to use antithrombotics. If antithrombotics are to be used, who will receive them? Additional research may shed light on these unanswered questions.
